Leírás és Paraméterek
SPA profilú öntött vas ékszíjtárcsa kúpos szorítós kivitelben. Maximálisan 13 mm széles szíjjal használható.
A kúpos szorító nem tartozéka az ékszíjtárcsának. A szorítót külön meg kell rendelni.
| Cikkszám | Tárcsa átmérő(mm) | Ékpályák száma | Szorító típusa |
| t_SPA_63mm_1 | 63 mm | 1 | TB 1008 |
| t_SPA_63mm_2 | 63 mm | 2 | TB 1008 |
| t_SPA_67mm_1 | 67 mm | 1 | TB 1108 |
| t_SPA_67mm_2 | 67 mm | 2 | TB 1108 |
| t_SPA_71mm_1 | 71 mm | 1 | TB 1108 |
| t_SPA_71mm_2 | 71 mm | 2 | TB 1108 |
| t_SPA_71mm_3 | 71 mm | 3 | TB 1108 |
| t_SPA_75mm_1 | 75 mm | 1 | TB 1108 |
| t_SPA_75mm_2 | 75 mm | 2 | TB 1108 |
| t_SPA_75mm_3 | 75 mm | 3 | TB 1108 |
| t_SPA_80mm_1 | 80 mm | 1 | TB 1210 |
| t_SPA_80mm_2 | 80 mm | 2 | TB 1210 |
| t_SPA_80mm_3 | 80 mm | 3 | TB 1210 |
| t_SPA_85mm_1 | 85 mm | 1 | TB 1210 |
| t_SPA_85mm_2 | 85 mm | 2 | TB 1210 |
| t_SPA_85mm_3 | 85 mm | 3 | TB 1210 |
| t_SPA_90mm_1 | 90 mm | 1 | TB 1210 |
| t_SPA_90mm_2 | 90 mm | 2 | TB 1610 |
| t_SPA_90mm_3 | 90 mm | 3 | TB 1610 |
| t_SPA_90mm_4 | 90 mm | 4 | TB 1615 |
| t_SPA_95mm_1 | 95 mm | 1 | TB 1210 |
| t_SPA_95mm_2 | 95 mm | 2 | TB 1610 |
| t_SPA_95mm_3 | 95 mm | 3 | TB 1610 |
| t_SPA_95mm_4 | 95 mm | 4 | TB 1615 |
| t_SPA_100mm_1 | 100 mm | 1 | TB 1610 |
| t_SPA_100mm_2 | 100 mm | 2 | TB 1610 |
| t_SPA_100mm_3 | 100 mm | 3 | TB 1610 |
| t_SPA_100mm_4 | 100 mm | 4 | TB 1615 |
| t_SPA_100mm_5 | 100 mm | 5 | TB 1610 |
| t_SPA_100mm_6 | 100 mm | 6 | TB 1615 |
| t_SPA_106mm_1 | 106 mm | 1 | TB 1610 |
| t_SPA_106mm_2 | 106 mm | 2 | TB 1610 |
| t_SPA_106mm_3 | 106 mm | 3 | TB 1610 |
| t_SPA_106mm_4 | 106 mm | 4 | TB 2012 |
| t_SPA_106mm_5 | 106 mm | 5 | TB 2012 |
| t_SPA_106mm_6 | 106 mm | 6 | TB 2012 |
| t_SPA_112mm_1 | 112 mm | 1 | TB 1610 |
| t_SPA_112mm_2 | 112 mm | 2 | TB 1610 |
| t_SPA_112mm_3 | 112 mm | 3 | TB 2012 |
| t_SPA_112mm_4 | 112 mm | 4 | TB 2012 |
| t_SPA_112mm_5 | 112 mm | 5 | TB 2012 |
| t_SPA_112mm_6 | 112 mm | 6 | TB 2012 |
| t_SPA_118mm_1 | 118 mm | 1 | TB 1610 |
| t_SPA_118mm_2 | 118 mm | 2 | TB 1610 |
| t_SPA_118mm_3 | 118 mm | 3 | TB 2012 |
| t_SPA_118mm_4 | 118 mm | 4 | TB 2012 |
| t_SPA_118mm_5 | 118 mm | 5 | TB 2012 |
| t_SPA_118mm_6 | 118 mm | 6 | TB 2012 |
| t_SPA_125mm_1 | 125 mm | 1 | TB 1610 |
| t_SPA_125mm_2 | 125 mm | 2 | TB 1610 |
| t_SPA_125mm_3 | 125 mm | 3 | TB 2012 |
| t_SPA_125mm_4 | 125 mm | 4 | TB 2012 |
| t_SPA_125mm_5 | 125 mm | 5 | TB 2012 |
| t_SPA_125mm_6 | 125 mm | 6 | TB 2012 |
| t_SPA_132mm_1 | 132 mm | 1 | TB 1610 |
| t_SPA_132mm_2 | 132 mm | 2 | TB 2012 |
| t_SPA_132mm_3 | 132 mm | 3 | TB 2012 |
| t_SPA_132mm_4 | 132 mm | 4 | TB 2012 |
| t_SPA_132mm_5 | 132 mm | 5 | TB 2517 |
| t_SPA_132mm_6 | 132 mm | 6 | TB 2517 |
| t_SPA_140mm_1 | 140 mm | 1 | TB 1610 |
| t_SPA_140mm_2 | 140 mm | 2 | TB 2012 |
| t_SPA_140mm_3 | 140 mm | 3 | TB 2517 |
| t_SPA_140mm_4 | 140 mm | 4 | TB 2517 |
| t_SPA_140mm_5 | 140 mm | 5 | TB 2517 |
| t_SPA_140mm_6 | 140 mm | 6 | TB 2517 |
| t_SPA_150mm_1 | 150 mm | 1 | TB 1610 |
| t_SPA_150mm_2 | 150 mm | 2 | TB 2012 |
| t_SPA_150mm_3 | 150 mm | 3 | TB 2517 |
| t_SPA_150mm_4 | 150 mm | 4 | TB 2517 |
| t_SPA_150mm_5 | 150 mm | 5 | TB 2517 |
| t_SPA_150mm_6 | 150 mm | 6 | TB 2517 |
| t_SPA_160mm_1 | 160 mm | 1 | TB 1610 |
| t_SPA_160mm_2 | 160 mm | 2 | TB 2012 |
| t_SPA_160mm_3 | 160 mm | 3 | TB 2517 |
| t_SPA_160mm_4 | 160 mm | 4 | TB 2517 |
| t_SPA_160mm_5 | 160 mm | 5 | TB 2517 |
| t_SPA_160mm_6 | 160 mm | 6 | TB 2517 |
| t_SPA_170mm_1 | 170 mm | 1 | TB 1610 |
| t_SPA_170mm_2 | 170 mm | 2 | TB 2012 |
| t_SPA_170mm_3 | 170 mm | 3 | TB 2517 |
| t_SPA_170mm_4 | 170 mm | 4 | TB 2517 |
| t_SPA_170mm_5 | 170 mm | 5 | TB 2517 |
| t_SPA_180mm_1 | 180 mm | 1 | TB 1610 |
| t_SPA_180mm_2 | 180 mm | 2 | TB 2012 |
| t_SPA_180mm_3 | 180 mm | 3 | TB 2517 |
| t_SPA_180mm_4 | 180 mm | 4 | TB 2517 |
| t_SPA_180mm_5 | 180 mm | 5 | TB 3020 |
| t_SPA_180mm_6 | 180 mm | 6 | TB 3020 |
| t_SPA_190mm_1 | 190 mm | 1 | TB 1610 |
| t_SPA_190mm_2 | 190 mm | 2 | TB 2012 |
| t_SPA_190mm_3 | 190 mm | 3 | TB 2517 |
| t_SPA_190mm_4 | 190 mm | 4 | TB 2517 |
| t_SPA_190mm_5 | 190 mm | 5 | TB 3020 |
| t_SPA_200mm_1 | 200 mm | 1 | TB 2012 |
| t_SPA_200mm_2 | 200 mm | 2 | TB 2517 |
| t_SPA_200mm_3 | 200 mm | 3 | TB 2517 |
| t_SPA_200mm_4 | 200 mm | 4 | TB 3020 |
| t_SPA_200mm_5 | 200 mm | 5 | TB 3020 |
| t_SPA_200mm_6 | 200 mm | 6 | TB 3020 |
| t_SPA_212mm_1 | 212 mm | 1 | TB 2012 |
| t_SPA_212mm_2 | 212 mm | 2 | TB 2517 |
| t_SPA_212mm_3 | 212 mm | 3 | TB 2517 |
| t_SPA_212mm_4 | 212 mm | 4 | TB 3020 |
| t_SPA_212mm_5 | 212 mm | 5 | TB 3020 |
| t_SPA_224mm_1 | 224 mm | 1 | TB 2012 |
| t_SPA_224mm_2 | 224 mm | 2 | TB 2517 |
| t_SPA_224mm_3 | 224 mm | 3 | TB 2517 |
| t_SPA_224mm_4 | 224 mm | 4 | TB 3020 |
| t_SPA_224mm_5 | 224 mm | 5 | TB 3020 |
| t_SPA_224mm_6 | 224 mm | 6 | TB 3020 |
| t_SPA_236mm_1 | 236 mm | 1 | TB 2012 |
| t_SPA_236mm_2 | 236 mm | 2 | TB 2517 |
| t_SPA_236mm_3 | 236 mm | 3 | TB 2517 |
| t_SPA_236mm_4 | 236 mm | 4 | TB 3020 |
| t_SPA_236mm_5 | 236 mm | 5 | TB 3020 |
| t_SPA_250mm_1 | 250 mm | 1 | TB 2012 |
| t_SPA_250mm_2 | 250 mm | 2 | TB 2517 |
| t_SPA_250mm_3 | 250 mm | 3 | TB 2517 |
| t_SPA_250mm_4 | 250 mm | 4 | TB 3020 |
| t_SPA_250mm_5 | 250 mm | 5 | TB 3020 |
| t_SPA_250mm_6 | 250 mm | 6 | TB 3020 |
| t_SPA_280mm_1 | 280 mm | 1 | TB 2012 |
| t_SPA_280mm_2 | 280 mm | 2 | TB 2517 |
| t_SPA_280mm_3 | 280 mm | 3 | TB 2517 |
| t_SPA_280mm_4 | 280 mm | 4 | TB 3020 |
| t_SPA_280mm_5 | 280 mm | 5 | TB 3535 |
| t_SPA_280mm_6 | 280 mm | 6 | TB 3535 |
| t_SPA_315mm_1 | 315 mm | 1 | TB 2012 |
| t_SPA_315mm_2 | 315 mm | 2 | TB 2517 |
| t_SPA_315mm_3 | 315 mm | 3 | TB 3020 |
| t_SPA_315mm_4 | 315 mm | 4 | TB 3020 |
| t_SPA_315mm_5 | 315 mm | 5 | TB 3535 |
| t_SPA_315mm_6 | 315 mm | 6 | TB 3535 |
| t_SPA_355mm_1 | 355 mm | 1 | TB 2012 |
| t_SPA_355mm_2 | 355 mm | 2 | TB 2517 |
| t_SPA_355mm_3 | 355 mm | 3 | TB 3020 |
| t_SPA_355mm_4 | 355 mm | 4 | TB 3020 |
| t_SPA_355mm_5 | 355 mm | 5 | TB 3535 |
| t_SPA_355mm_6 | 355 mm | 6 | TB 3535 |
| t_SPA_400mm_1 | 400 mm | 1 | TB 2012 |
| t_SPA_400mm_2 | 400 mm | 2 | TB 2517 |
| t_SPA_400mm_3 | 400 mm | 3 | TB 3020 |
| t_SPA_400mm_4 | 400 mm | 4 | TB 3020 |
| t_SPA_400mm_5 | 400 mm | 5 | TB 3535 |
| t_SPA_400mm_6 | 400 mm | 6 | TB 3535 |
| t_SPA_450mm_1 | 450 mm | 1 | TB 2012 |
| t_SPA_450mm_2 | 450 mm | 2 | TB 2517 |
| t_SPA_450mm_3 | 450 mm | 3 | TB 3020 |
| t_SPA_450mm_4 | 450 mm | 4 | TB 3020 |
| t_SPA_450mm_5 | 450 mm | 5 | TB 3535 |
| t_SPA_450mm_6 | 450 mm | 6 | TB 3535 |
| t_SPA_500mm_1 | 500 mm | 1 | TB 2517 |
| t_SPA_500mm_2 | 500 mm | 2 | TB 2517 |
| t_SPA_500mm_3 | 500 mm | 3 | TB 3020 |
| t_SPA_500mm_4 | 500 mm | 4 | TB 3020 |
| t_SPA_500mm_5 | 500 mm | 5 | TB 3535 |
| t_SPA_500mm_6 | 500 mm | 6 | TB 3535 |
| t_SPA_560mm_2 | 560 mm | 2 | TB 3020 |
| t_SPA_560mm_3 | 560 mm | 3 | TB 3020 |
| t_SPA_560mm_4 | 560 mm | 4 | TB 3020 |
| t_SPA_560mm_5 | 560 mm | 5 | TB 3535 |
| t_SPA_560mm_6 | 560 mm | 6 | TB 3535 |
| t_SPA_630mm_1 | 630 mm | 1 | TB 2517 |
| t_SPA_630mm_2 | 630 mm | 2 | TB 3020 |
| t_SPA_630mm_3 | 630 mm | 3 | TB 3020 |
| t_SPA_630mm_4 | 630 mm | 4 | TB 3535 |
| t_SPA_630mm_5 | 630 mm | 5 | TB 3535 |
| t_SPA_630mm_6 | 630 mm | 6 | TB 4040 |
| t_SPA_800mm_3 | 800 mm | 3 | TB 3535 |
| t_SPA_800mm_4 | 800 mm | 4 | TB 3535 |
| t_SPA_800mm_5 | 800 mm | 5 | TB 4040 |
| t_SPA_800mm_6 | 800 mm | 6 | TB 4040 |
| t_SPA_900mm_3 | 900 mm | 3 | TB 3535 |
| t_SPA_900mm_4 | 900 mm | 4 | TB 3535 |
| t_SPA_900mm_5 | 900 mm | 5 | TB 4040 |
| t_SPA_1000mm_3 | 1000 mm | 3 | TB 3535 |
| t_SPA_1000mm_4 | 1000 mm | 4 | TB 4040 |
| t_SPA_1000mm_5 | 1000 mm | 5 | TB 4545 |
| Anyaga | GG25 öntöttvas |
| Kivitele | kúpos szorítós |
| Felületkezelés | foszfátozott |
| Kiegyensúlyozás | 35 m/s-os kerületi sebesség melett |
| Szabvány szám | ISO 4183 és DIN 2211-3 |
| Ékszög | ha elméleti átmérő <= 118mm akkor 34°, ha elméleti átmérő > 118mm akkor 38° |
